Power Supply Function
Run the Vehicle Waveform
After turning on [On/Off], the output of the vehicle waveform is triggered accord-
ing to the selected trigger method.
The trigger method of the vehicle waveform is consistent with the trigger
method of the List function, that is, the List trigger source is also effective for
the vehicle waveform.
Stop the Vehicle Waveform Running
If you want to stop during the vehicle waveform output, you can do the following:
Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter
the function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion, you can press the Left/Right key to select Stop, then the running will be
stopped, and the Function menu item will be displayed, you can re-enter the
Function menu for editing; if Reset is selected, it means to stop the present run-
ning and return to the main interface to wait for the next trigger operation; if
Pause is selected, it means that the present running is suspended, and you can
continue to run by selecting Resume.
4.6.3.1 Automotive Starting Waveform
The IT6000C series power supply has built-in 12V or 24V DIN40839 waveform.
This test verifies the behavior of a DUT during and after cranking. This wave-
form can reproduce the voltage curve for automotive power network confirms to
DIN40839 standard, thus facilitating quick call by customers.
For automotive startup voltage waveform, the startup voltage can also be set
based on customers’ requirements. In this way, the user can create waveform
between 8V to 32V.
DIN40839
Evaluation of automotive starting
waveform
12V
Select the automotive
starting waveform with
a starting voltage of
12V.
24V
Select the automotive
starting waveform with
Copyright © Itech Electronic Co., Ltd.
86
