time, output will be off automatically. If in OFF mode, the timer function will not
be enabled. The default set is OFF.
Reset (RESET)
This item is used to reset all items in the menu. If you select YES, then unit will
restored to factory setting. If you select NO, all settings in the menu will remain
unchanged.
List (List Set)
IT6700 series power supply provides 9 list files, each list file includes 150 steps.
Before you edit a list file, please set the trigger mode: manual mode.
Press (Shift)+ (Menu)button to enter the menu, then press
direction key to select >SYST SET option, after that please push
button to confirm. At last to press direction key to select >Trig MANUAL and
push button to confirm.
You can make the output change order by editing every step value of list
operation. The parameters you need to edit includes: single-step voltage,
single-step current, single-step delay time and whether to go on the next step.
Besides, you also need to set the repeat times and save list sequence file. After
the editing process, at this time if a trigger signal is received, power supply will
begin to work according to the sequence steps you’ve edit. Now we take five
steps for an example.
Operation steps:
1. Press (Shift) + (Menu)button to enter the menu.
2. VFD display >MAX VOLT, press to select >LIST SET, press
to confirm
3. VFD display >LIST STATE, press to select >LIST EDIT, press
to confirm.
4. VFD display >TIME SEC, press to confirm, go to the next step,
you can also through button to select >TIME MIN time unit, press
to confirm.
5. VFD display >VSET 0.0, press number key to or through rotary
knob to set voltage, after that press to confirm.
6. VFD display ISET 0.00, press number key to or rotary knob to
set the single-step current, press to confirm.
7. VFD display SEC 0.100, press number key to or rotary knob to
set single-step delay time, press to confirm(range is 0.1-9999).
If you choose MIN for the 4
th
step, VFD will display MIN 0.100 for this step,
time range 0.1~9999min.
8. VFD display NEXT >YES, press to confirm.
9. Repeat the steps from 5) to 8) and set the four steps’ voltage/current and
delay time separately. When screen display NEXT>YES in the fourth step
edit process, please press to select NEXT >NO, press to
confirm.
