Quick Start
Copyright © Itech Electronic Co., Ltd. 12
Chapter2 Quick Start
This chapter introduces the front panel, the rear panel, key functions and VFD
display function of the electronic load, make sure that you can quickly know the
appearance, instruction and the key function before you operate the load. Help
you better use this series of loads.
2.1 Brief Introduction
IT8500+ series is a single-channel programmable electronic load. With power
ranges from 150W to 3000W. The user can perform online voltage
measurements and adjustments or simulate short circuit test using the simple
keypad on the front panel. IT8500+ also offers a full-featured battery mode for
discharging test. IT8500+ series DC load is a versatile instrument for static and
dynamic testing of power supplies, batteries, AC-DC/DC-DC converters, battery
chargers, provides user the best testing solution.
Model
Voltage
Current
Power
Communication
Interface
IT8511+
120V
30A
150W
DB9(TTL)
IT8511A+
150V
30A
150W
DB9(TTL)
IT8511B+
500V
10A
150W
DB9(TTL)
IT8512+
120V
30A
300W
DB9(TTL)
IT8512A+
150V
30A
300W
DB9(TTL)
IT8512B+
500V
15A
300W
DB9(TTL)
IT8512C+
120V
60A
300W
DB9(TTL)
IT8512H+
800V
5A
300W
DB9(TTL)
IT8513A+
150V
60A
400W
DB9(TTL)
IT8513B+
500V
30A
600W
Standard USB/RS232
IT8513C+
120V
120A
600W
DB9(TTL)
IT8514B+
500V
60A
1500W
Standard USB/RS232
IT8514C+
120V
240A
1500W
Standard USB/RS232
IT8516C+
120V
240A
3000W
Standard USB/RS232
2.2 Product Feature
High-visibility vacuum fluorescent display (VFD)
Measurement resolution: 0.1mV,0.1mA
Voltage and current measurement speed: up to 40KHZ
Four operation modes: CV (Constant Voltage), CC, CR,CW
Battery test function
OCP test, OPP test
Measurement function: measuring voltage rise and fall time
Automatic test function
List mode, which can simulate a variety of load state changes
Short circuit function
Remote sense function
Memory capacity to save/recall setting parameters: 100 registers
Intelligent fans
Build-in Buzzer as alarm signal
Power off memory function
