iTechworld 40Amp MPPT User Manual

6. Specifications
6.1 Operating Parameters
- 19 -
Input
System Rated Voltage
12/24VDC Auto sensing
Max Open Voltage of
Solar Panel
100VDC (at the lowest temperature)
92VDC (at standard temp of 25°C)
Max Solar Input Power
12VDC System
520W
24VDC System
1040W
Battery Voltage Range
8V DC – 32VDC
Output
Rated Charge Current
40A
Battery Types
Sealed Lead Acid, Flooded Lead Acid, Gel,
LiFePO
4
(i.e. iTECH120X), LiNiMnCoO
2
(LiPO)
Static Loss
≤50mA
Temperature
Compensation
Coefficient
-4mV/°2V(25°C)
LCD Temperature
-20°C~+70°C
Operating
Temperature
-20°C~+55°C
Storage Temperature
-30°C~+80°C
Working Humidity
≤90% non-condensing
Grounding
Common Positive
Dimensions H x W x D
215mm x 145mm x 75mm
Wire Terminal Size
16mm
2
/6AWG
Weight
1.30KG
