ITRON 233 User Manual

1313
Outlet pressure range
Regulator Type Spring range (Wds) Spring code Wire-Ø Spring color
133 with Gas loss
protection
9-15 mbar
14-20 mbar
18-26 mbar
24-40 mbar
38-53 mbar
955-200-08
955-200-09
955-201-06
955-202-98
955-200-11
1,6 mm
1,8
2,25
2,5
2,4
red
blue
silver
yellow
orange
133
8-16 mbar
12-20 mbar
15-35 mbar
30-70 mbar
50-140 mbar
100-210 mbar
955-200-08
955-200-09
955-200-10
955-200-11
955-200-12
955-200-83
1,6 mm
1,8
2,0
2,4
3,0
3,4
red
blue
green
orange
black-white
silver
133 HP 140 – 420 mbar 955-200-84 4,5 mm black
233-12 / 244-12 8-16 mbar
12-20 mbar
15-35 mbar
30-70 mbar
70-140 mbar
100-210 mbar
955-200-13
955-200-14
955-200-15
955-200-16
955-200-17
955-200-18
2,8
3,2
3,6
4,5
5,6
6,3
red
blue
green
orange
black
metallic
233-8 / 244-8 30-70 mbar
70-140 mbar
140-300 mbar
210-450 mbar
955-200-15
955-200-16
955-200-17
955-200-18
3,6 mm
4,5
5,6
6,3
green
orange
black-white
metallic
233-8 HP 420-700 mbar 955-200-69+
955-200-18
4,0 mm
6,3
silver
metallic
Spring range of SSV 033, OPSO
Function Spring range (Wdso) Spring code Wire-Ø Spring color
OPSO
(Pdso)
40-70 mbar
50-150 mbar
140-450 mbar
955-200-22
955-200-23
955-200-24
1,4 mm
1,6
2,6
red
blue
green
Spring range of SSV I and II, OPSO and UPSO
Function Spring range
(Wdso & Wdsu)
Spring code Wire-Ø Spring color
OPSO
(Pdso)
20-60 mbar
50-120 mbar
100-400 mbar
300-600 mbar
400-1000 mbar
955-200-22
955-200-23
955-200-24
955-200-52
955-202-42
1,4 mm
1,6
2,6
2,8
3,2
red
blue
green
brown
silver
UPSO (Pdsu) 8-50 mbar 955-200-32 0,9 mm red
Attention: ∆p between pds and pdso max 150 mbar!
Accuracy class AC / Lock-up pressure SG: Accuracy group (SSV):
Outlet pressure AC SG OPSO AG
8 - 20 mbar 20 30 20 – 400 mbar 10
>20 - 40 mbar 10 20 0,4 – 1,0 bar 5
>40 - 700 mbar 5 10 UPSO AG
8 – 20 mbar 30
20 – 50 mbar 10
