look like this:
4. Gently push the back of the laptop down onto the dock until the latch hooks snap into place
over the rear of the laptop.
5. When the latch hooks are engaged the latch button on the front of the dock will move into the
latched position.
6. Best practice is to now lock the laptop in place. See Locking and Unlocking the Dock on
page 24.
Locking and Unlocking the Dock
When a tablet or laptop computer is attached to its dock, the dock must be locked to properly
secure the computer.
1. Lock the dock by inserting the dock key into the dock lock and turning it clockwise until the
lock is in the locked position.
07 May 2020 815-0207-00 REV 000 Itron, Inc. Page 24 of 44
Vehicle Preparation and Hardware Installation Guide 3 Installing Mobile Collection Components
