Installation
7. Fix the main unit to a suitable, accessible location with some
ventilation. Use the provided 3M tape or mount with screws so the
install is secure.
8. Align the direct of the camera lens to the front referring to the camera
direction alignment guide (arrow make printed on each camera.
9. Connect the GPS receiver (optional) to the correct port on the main
control and mount receiver so it has a clear view of the sky (do not
mount behind dark tint strips or close to metal.
10. Arrange all cables with cable holders to provide a neat installation.
Check all connections at the main control unit to ensure all the correct
ports have been used.
11. Power on the unit for normal operation. Installation is now complete.
13
When the external GPS receiver is installed, please
make sure the GPS receiver face up to the sky and
fully exposed through the windshield. Then, put the
GPS receiver cable into the GPS port of main unit.
