ITW Mima Ecomat EASY - Photocell Settings

Technical Data
Sensing Range = 2000mm
Blind Range = ≤75mm
Operational Voltage = 12VDC...240VDC ± 10 %
= 24VAC...240VAC ± 10 %
Power consumption = 3VA
Correct Potentiometer Settings:
MODE = D.ON (Dark ON)
SENSITIVITY (SENS) = MAX - 10º (nearly MAX)
Led indicators
YELLOW = Output Status
(ON when no object in range)
RED = Fault indicator
Weak signal
OBJECT
MODE
D.ON L.ON
SENS
MIN MAX
Photocell settings
WRAPPING SETTINGS
