No movement, Horizontal bars on display
1. Emergency Stop button can be activated Unlock the button
2. Film loading door can be open Close the door
3. Automatic fuses AF2-AF3 can be tripped Un-trip the fuse/s
4. Connector 2 on MPU-controller can be disconnected Connect the plug (See page 27)
5. Glass-tube fuse no.1 on MPU-controller can be blowed Replace the fuse (See page 27)
TROUBLESHOOTING
15
No movement, horizontal bars on display
