Overlapping
OVERLAPPING DEGREE
-No Overlapping55
-No Overlapping105
12028 %510
26060 %110
a =
[mm]
OVERLAPPING
DEGREE
CARRIAGE
SPEED
TURNTABLE
SPEED
a
a
Measured with Mima
Lite film, EUR-pallet
(800*1200), medium
film tension
WRAPPING SETTINGS
7
MAX overlapping
(Free space between film 180mm)
(Free space between films 35mm)
