Figure 7
Engine oil level sensor
This sensor is used to indicate that the su mp oil level is t oo low.
Features:
-maxpressure : 5-28Vdc. .....
- resistanc e 130 mA a 28 Vdc Max..........
- work temperature -40˚C / + 125˚C...
- Tightening torque 10 ± 2 Nm....
A. Electrical contac t in open position — B. Electrical cont act in close position - low level in the oil sump
SECTION 3 - INDUSTRIAL APPLICATION
49
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
