SECTION 3 - INDUSTRIAL APPLICATION
67
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
FAULTS TABLE
5 Volt Supply Above Normal 262-3
5 Volt Supply Below Normal 262-4
8 Volt Supply Above Normal 41-3
8 Volt Supply Below Normal 41-4
Alternator Disable Relay Open Circuit 1002-5
Alternator Disable Relay Short Circuit 1002-6
Alternator Pump Pressure Sen sor Open / Short To Battery + 1003-3
Atmospheric Pressure Sensor Open / Short To Battery + 274-3
Atmospheric Pressu re Sensor Open - Short to Ground 274-4
Battery Voltage Above Normal 168-3
Battery Voltage Below Normal 168-4
Diagnostic Lamp Open Circuit 1266-5
Diagnostic Lamp Short Circuit 1266-6
Engine Coolant Temperature Sensor Open / S hort To Bat tery + 110-3
Engine Coolant Temperature Sensor Short to Ground 110-4
Engine Coolant Fan Pump Pressure Sensor Short to Ground 290-4
Engine Oil Pressure Sensor Open / Short To Battery + 100-3
Engine Oil Pressure Sensor Short to Ground 100-4
Engin e Oil Refill Relay Open Circuit 1000-5
Engine Oil Refill Relay Short Circuit 1000-6
Engine Oil Temperature Sensor Open / Short To Battery + 175-3
Engine Oil Temperature Sensor Short to Ground 175-4
Engine Starter Relay Open Circuit 444-5
Engine Starter Relay Short Circuit 444-6
Fuel Filter Heater Relay Open Circuit 1001-5
Fuel Filter Heater Relay Short Circuit 1001-6
Fuel Rail Pressure Control Valve # 1 Machanical System 1779-7
Fuel Rail Pressure Control Valve # 1 Open Circuit 1779-5
Fuel Rail Pressure Control Valve # 1 Short Circu it 1779-6
Fuel Rail Pressure Sensor # 1 Open / Short To Batt ery + 1797-3
