Iveco VECTOR 8 User Manual

SECTION 4 - OVERHAUL AND TECHNICAL SPECIFICATIONS 39
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
TIGHTENING TORQUE
COMPONENT TORQUE
Nm kgm
C
y
linder head fi
x
in
g
bolt
(
*
)
p
re
—
tor
q
ue
angle
guard—torque
70
240°
220 ÷ 390
7
240°
22 ÷ 39
Cran
k
case ca
p
fi
x
in
g
bolt
(
*
)
p
re
—
tor
q
ue
angle
guard—torque
160
240°
600 ÷ 1000
16
240°
60 ÷ 100
Cran
k
case ca
p
side fi
x
in
g
bolt
(
*
)
p
re
—
tor
q
ue
angle
guard—torque
70
120°
260 ÷ 460
7
120°
26 ÷ 46
Connectin
g
rod ca
p
fi
x
in
g
bolt
(
*
)
p
re
—
tor
q
ue
angle
guard—torque
90
60°
170 ÷ 230
9
60°
17 ÷ 23
En
g
ine fl
y
wheel fi
x
in
g
bolt
(
*
)
p
re
—
tor
q
ue
angle
guard—torque
350
120°
910 ÷ 1600
35
120°
91 ÷ 160
Dam
p
er fi
x
in
g
bolt
(
*
)
p
re
—
tor
q
ue
angle
guard—torque
160
120°
540 ÷ 960
16
120°
54 ÷ 96
Nut fixing front cover oil sump (M10x1.5) 38 ÷ 45 3.8 ÷ 4.5
Bolt fixing oil sump to front cover and crankcase (M10x1.5) 38 ÷ 45 3.8 ÷ 4.5
Bolt fixing crankcase front gearbox (M8x1.25) 22 ÷ 27 2.2 ÷ 2.7
Bolt fixing front gearbox and cover to crankcase (M8x1.25) 22 ÷ 27 2.2 ÷ 2.7
Bolt fixing front cover to front gearbox (M8x1. 2 5 ) 22 ÷ 27 2.2 ÷ 2.7
Nut fixing front cover to front gear casing 27 ÷ 33 2.2 ÷ 2.7
Bolt fixing flywheel housing to crankcase (M12x1.75) 86 ÷ 105 8.6 ÷ 10.5
Bolt fixing flywheel casing to crankcase (M14x2) 135 ÷ 165 13.5 ÷ 16.5
Bolt fixing flywheel casing to crankcase (M14x2) 135 ÷ 165 13.5 ÷ 16.5
Bolt fixing gear pin centring (M10x1.5) (*) 45 ÷ 50 4.5 ÷ 5.0
Bolt fixing centring pin (M12x1.75) (*) 100 ÷ 110 10.0 ÷ 11.0
Bolt fixing cylinder head cover (M8x1.25) 20 ÷ 24 2.0 ÷ 2.4
Bolt fixing clearance adjustment cover (M6x1) 7 ÷ 10 0.7 ÷ 1.0
Bolt fixing left and right intake manifold to cylinder head (M10x1.5) 38 ÷ 45 3.8 ÷ 4.5
Bolt fi
x
in
g
e
x
haust manifold
(
M10
x
1.5
)
(
**
)
N. 12 bolts from front side (on both side) torque
N. 4 bolts from rear side (on both side) pre—torque
torque
47 ÷ 53
47 ÷ 53
64 ÷ 70
4.7 ÷ 5.3
4.7 ÷ 5.3
6.4 ÷ 7.0
Bolt fixing thrust plate to crankcase (M8x1.25) (*) 22 ÷ 27 2.2 ÷ 2.7
Bolt fixing inlet pipe to the right and left intake manifolds (M8x1.25) 22 ÷ 27 2.2 ÷ 2.7
Bolt fixing driving gear to driven gear governing camshaft (M10x1.5) (*) 49 ÷ 60 4.9 ÷ 6.0
Bolt fixing rocker—arm assembly to head (M12x1.75) (*) 80 ÷ 89 8.0 ÷ 8.9
Nut adjusting clearance (rocker arms) (M10x1.25) (*) 34 ÷ 44 3.4 ÷ 4.4
Bolt fixing crankshaft rear gear (M8x1.25) (*) 22 ÷ 27 2.2 ÷ 2.7
Bolt fixing gear to PTO (M12x1.75) (*) 86 ÷ 105 8.6 ÷ 10.5
Bolt fixing PTO to spacer (M12x1.75) 74 ÷ 90 7.4 ÷ 9.0
Bolt fixing PTO spacer to gearbox (M12x1.75) 74 ÷ 90 7.4 ÷ 9.0
Bolt fixing gear assembly to camshaft (M12x1.75) 86 ÷ 105 8.6 ÷ 10.5
Bolt fixing phonic wheel to gear (M8x1.25) 24 ÷ 30 2.4 ÷ 3.0
Bolt fixing injector bracket to cylinder head (M10x1.5) (*) 32 ÷ 36 3.2 ÷ 3.6
Nut fixing turbo to exaust manifold (M12x1,75) 55 ÷ 65 5,5 ÷ 6,5
Bolt fixing oil delivery pipe to turbo (M8x1.25) 22 ÷ 27 2.2 ÷ 2.7
