IXOLIFT DataLift 250 - Overview of Main Components

4
OPERATING MANUAL – DataLift 250
1 REMOTE CONTROL 10 MAST
2 DIRECTIONAL LOCK LEVER 11 HANDLE BAR
3 EMERGENCY STOP 12 TABLE
4 BATTERY INDICATOR 13 FRONT WHEEL & LOCKING BOLT
5 MAIN SWITCH 14 BACK WHEELS
6 CHARGE INLET 15 BLOCK WHEEL
7 USER MANUAL COMPARTMENT 16 CABLE CHAIN
8 BRAKE LEVER 17 TABLE HANDLE
9 COLLISION SENSOR
1
2
3
4
5
6
8
12
13
14
17
16
OVERVIEW OF THE MAIN COMPONENTS
7
11
14
15
15
9
10
