OPERATING MANUAL – DataLift 250
MAINTENANCE
OPENING OF THE BACK COVER
Park the DataLift safely, lock the position with the brake (8) and switch off the main switch (5). Loosen the 4
screws on the back cover, remove the back cover.
Do not connect the unit to mains power while the back cover is open!
Clamping risk at the winch!
