1.14 iZone 325 - Optional equipment for iSave addition (7-12 Zones)
Note:
When the iSave option is used with the CEXT the iZone system is limited to
a maximum of 12 Zones
5!
'%&
5!
'%&
#! 
'%&
#! 
'%&
@
Use Zone 14 port on CEXT for Outside Air
dampers
Use Zone 13 port on CEXT for Return Air
dampers
