iZone 225 - Izone 325-Wiring Connection to Samsung Units


1.19 iZone 325 - Wiring connection to Samsung units
Unit Make Connection
Samsung 1. Connect a shielded, 2 core, twisted pair control cable from the C225 / C325S to the
F3 / F4 in the fan coil unit. (This cable is supplied by the installer). Polarity is critical see
Fig (F) & (G) below for correct connection.
