J.P. Instruments EDM-900 User Manual

For Your Safe Flight ............................................. Page 43
HP Constant= 125
10 999
Hold NEXT and button 2 until you see
ADJUST. Tap PLUS or MINUS to adjust
(%HP display will reflect changes). Hold
NEXT and button 2 to save changes.
Map Adjustment +0.0
-3.0  +3.0
Correct the MAP to the altimeter setting at
a sea level airport ±3.0 inHg. Hold NEXT
and button 2 for 5 seconds until you see
ADJUST. Use PLUS or MINUS to adjust.
Tap SAVE to save changes. Tap NEXT to
skip to next item.
K-Factor 1 29.90
00.10  99.99
Set the instrument’s K-factor to match the
fuel flow transducer K-factor and
performance. Hold DIGIT and button 2 for
5 seconds until you see ADJUST. Use
DIGIT, PLUS or MINUS to adjust. Hold
NEXT and button 2 to save changes.
K-Factor 2
00.10  99.99
Applies only to pressurized carburetors.
CARB? Y
YES  NO
Set to N if injected.
CARB = 1
PLUS 
MINUS
F/F Filter (Higher the number the better
the dampening effect) (Fuel pump pulses).
GPS Format = 6
0 8
Adjust to set the GPS Communications
format. Hold NEXT and button 2 for 5
seconds until you see ADJUST. Use
PLUS or MINUS to adjust. Tap SAVE to
save changes. Tap NEXT to skip to next
item. See page 51.
Time: 18:23:59
00:00:00 
23:59:59
Hold NEXT and button 2 for 5 seconds
until you see ADJUST. Use Hours,
Minutes, Seconds to adjust. Tap SAVE
to save changes. Tap NEXT to skip to next
item.
Date: 05/14/09
01/01/00 
12/31/99
Hold NEXT and button 2 for 5 seconds
until you see ADJUST. Use Month, Day,
Year to adjust. Tap SAVE to save
changes. Tap NEXT to skip to next item.
RECORD TIME: 6
PLUS 
MINUS
Record time in seconds.
END? Yes
END? Yes
Yes exits the pilot program mode.
No reenters pilot program mode.
FACTORY Mode
Stays on for two seconds.
