Jackson CONSERVER XL User Manual

LEGEND:
A - Electrical connection
B - Water inlet 1/2" I.P.S
C - Drain connection 2" I.P.S
All vertical dimensions are +/- 1/2" from floor
due to adjustable bullet feet.
78 [1981mm]
13 [330mm]
C
B
65
1
4
[1658mm]
44 [1118mm]
[635mm]
4 [102mm]
B
A
13
1
4
[337mm]
11
1
2
[295mm]
68 1/2 [1740mm]
6 3/4 [171mm]
15
1
4
[387mm]
11 1/4 [283mm]
34 [864mm]
17
1
4
[438mm]
MAXIMUM DISH CLEARANCE
C
48 1/2 [1232mm]
A
Conserver XL Series Installation & Operation Manual 7610-002-04-66
Issued: 11-07-2006 Revised: 10-22-2007
SECTION 1: SPECIFICATION INFORMATION
RDIMENSIONS CONSERVER AXL2-CMR
7
