73
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
2810424 1 Cable, Engine Ground Engine Mount to Frame
2 4122840 2 Headlight REFERENCE L-1 & L-2, See 42.1
4123183 1 • Bulb
3 4122841 1 Controller REFERENCE U-6, See 42.1
4 5003282 2 • Fuse, 20 Amp REFERENCE F-1 & F-2, See 42.1
5 367631 4 Spacer
6 366931 1 Battery REFERENCE B-1, See 42.1
7 441668 4 Carriage Bolt, 1/4-20 x 1-1/4”
8 444708 4 Locknut, 1/4-20 Center
9 445796 2 Nut, 3/8-16 Spiralock Flange
10 444310 4 Nut, #10-24 Hex
11 473142 1 Cable Tie
12 2810213 1 Cable, Negative Battery Battery to Muffler Bracket
13 3007777 1 Cable, Positive Battery Battery to Starter
14 4128262 1 Body Wire Harness
15 4126082 2 • Relay-SPDT With Diode REFERENCE K-1 & K-2, See 42.1
16 446118 4 Lockwasher, #10
17 403910 4 Screw, #10-24 x 1/2” Truss Head
18 361439 1 Circuit Breaker, 12V 50A REFERENCE CB-1, See 42.1
19 3009251 1 Tab, Harness
20 400258 2 Screw, 3/8-16 x 3/4” Hex Head
To Next Page
