49
> Change from previous revision
12
16
16
18
17
16
15
10
11
11
13
14
14
1
2
3
8
9
5
6
7
4
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
450190 2 Screw, M8-1.25 x 16 mm Hex Head
4133238 1 Kit, Remote Oil Filter Included with Engine
2 4133239 1 • Adapter, Engine Oil Filter
3 4133240 1 • Plug, Engine Oil FIlter
4 4133241 1 • O-Ring
5 4133242 1 • Washer
6 4133243 1 • Head, Engine Oil FIlter
7 4113986 1 Engine Oil Filter Included with Engine
8 4133305 1 Hose, Engine to Filter
9 4133306 1 Hose, Filter to Engine Oil Cooler
10 4133307 1 Hose, Engine Oil Cooler to Engine
11 366526 2 Clamp, 1/4” to 5/8” Dia Hose
12 446136 2 Lockwasher, 5/16 Heavy
13 4134468 1 Adapter, Straight
14 4133808 2 Adapter, Straight
15 4133296 1 Engine Oil Cooler
16 4133252 4 Tie, 3 Piece Cooler Mounting
17 361831 4 Tube, Spacer
18 452004 4 Flat Washer, 1/4
11.1 Remote Engine Oil Cooler
Serial No. All
