75
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
548905 9 Screw, 3/8-16 x 1” Serrated Flange
2 REF 3 Deck Assembly See 31.1
3 4125547 3 Front Deck Pivot
4 4127480 2 • Bushing
5 471214 1 • Straight Grease Fitting
6 4125919 1 Center Lift Arm
7 3010489 2 • Bushing
8 471214 1 • Straight Grease Fitting
9 4126447 6 Pin, Arm
10 4126450 3 Pin, Cylinder
11 4127192 6 Plastic Washer
12 4127556 3 Nut, 1-1/4-7 Slotted Hex
13 4131849 6 Shoulder Bolt, 3/4 x 5/8-11 x 2-1/8”
14 444752 6 Locknut, 5/8-11 Center
15 452016 6 Flat Washer, 5/8
16 310452 6 Flat Washer
17 460068 3 Cotter Pin, 1/4 x 2”
18 4131963 6 Spacer, Cylinder
19 4171884 1 Right Front Lift Arm
20 3010489 2 • Bushing
21 471221 1 • 90° Grease Fitting
22 4171883 1 Left Front Lift Arm
23 3010489 2 • Bushing
24 471221 1 • 90° Grease Fitting
25 4137128 3 Cylinder, Lift
4137138 1 • Seal Kit
26 471214 3 Straight Grease Fitting
27 471221 3 90° Grease Fitting
28 445783 9 Nut, 3/8-16 Whizlock Flange
29 4134575 2 Pad, Step
30 4181006 2 Pin, Arm
31 400198 2 Screw, 5/16-18 x 2-1/4”
32 444718 2 Locknut, 5/16-18 Center
To Next Page
