77
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
4131422 2 Pin, Rear Cylinder
2 4131420 2 Pin, Rear Lift Arm
3 4126450 2 Pin, Cylinder
4 445783 10 Nut, 3/8-16 Whizlock Flange
5 548905 4 Screw, 3/8-16 x 1” Serrated Flange
6 REF 2 Deck Assembly See 31.1
7 548907 2 Screw, 3/8-16 x 1/1/4” Ser Flange
8 4127192 4 Washer, Plastic
9 452016 4 Flat Washer, 5/8”
10 310452 4 Flat Washer, 3/4”
11 4131849 4 Shoulder Bolt, 3/4 x 5/8-11 x 2-1/8
12 444752 4 Locknut, 5/8-11 Center
13 4125180 2 Rear Deck Pivot
14 4127480 2 • Bushing
15 471214 1 • Straight Grease Fitting
16 4131965 2 Spacer, Cylinder
17 4131964 2 Spacer, Cylinder
18 4132846 2 Rear Lift Arm
19 3010489 2 • Bushing
20 471221 1 • 90° Grease Fitting
21 4127556 2 Nut, 1-1/4-7 Slotted Hex
22 460076 2 Cotter Pin, 1/4 x 3”
23 4137128 2 Cylinder, Lift
4137138 1 • Seal Kit
24 471214 2 Straight Grease Fitting
25 471221 2 90° Grease Fitting
26 4134626 AR Pad, Deck Stop
Add pads as required to prevent
deck contacting engine oil pan.
27 4136022 2 Deck Stop
28 4137716 AR Deck Stop
Add as required to prevent deck
contacting engine oil pan.
To Next Page
