91
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
4134588 1 Shim Kit
● 2N/S1O-Ring
3 4134589 1 Charge Relief Spring
4 4134590 1 Charge Relief Valve
5 4134591 2 O-Ring
6 4134592 1 Needle Bearing
7 4134594 1 Roller Bearing
8 4134595 2 Retaining Ring
9 4134596 2 Ring
10 4134597 1 Variable Swashplate
11 4134606 1 • Pin
12 4134607 1 • Pin
13 4134608 2 Journal Bearing
● 14 5003433 1 Shaft Seal
● 15 NS 1 Front Cover Gasket
16 4134609 1 Pump Shaft
17 4134610 1 Valve Plate
18 4134612 1 Bypass Valve
● 19 N/S 1 • Backup Ring
● 20 N/S 1 • O-Ring
21 5003434 2 Relief Valve
22 4134613 1 • O-Ring
23 4134614 1 Cylinder Block Kit
● 5003034 1 Seal Kit Includes all Items marked ●
To Next Page
