96
AR-522
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B-1 See 28.1 366931 Battery
CB-1 See 28.1 361439 50 Amp Circuit Breaker (Alternator)
F-1 See 28.1 5003282 20 Amp Fuse (Ignition Circuit) Included in Controller
F-2 See 28.1 5003282 20 Amp Fuse (Lights) Included in Controller
K-1 See 28.1 4126082 Glow Plug Relay
K-2 See 28.1 4126082 Starter Relay
K-3 Not Shown Cruise Control Magnet (Option)
K-4 Not Shown 4134270 Fuel Solenoid Included with Engine
K-5 See 37.1 4134530 Raise Solenoid Coil
K-6 See 37.1 4142009 Lower Solenoid Coil
K-7 See 34.1 4134532 Mow Coil
L-1 See 28.1 4123183 Left Headlight Bulb
L-2 See 28.1 4123183 Right Headlight Bulb
L-3 See 4.1 N/S Alternator Light Included in 4130148
L-4 See 4.1 N/S Glow Plug Light Included in 4130148
L-5 See 4.1 N/S Engine Oil Pressure Light Included in 4130149
L-6 See 4.1 N/S Hydraulic Filter Pressure Light Included in 4130149
L-7 See 4.1 366751 Hydraulic Level Light
M1 Not Shown 556988 Starter Motor Included in Engine
M2 See 16.1 4132489 Fuel Pump
R-1 See 16.1 3006337 Fuel Sender
R-2 See 14.1 364501 Temperature Sender
R-3 Not Shown 556996 Glow Plugs Included in Engine
SW-1 See 19.1 556419 Hydraulic Filter Pressure Switch
SW-2 See 4.1 4128888 Ignition Switch
OFF-None
Run - A+B
GP - A+B+D
Start - A+B+C+D
SW-3 See 4.1 4130132 Light Switch
SW-4 Not Shown Cruise Control Switch (Option)
SW-5 See 4.1 4130133 Horn Switch
SW-6 See 4.1 4137524 Traction Control System Switch
SW-7 See 5.1 4125831 Neutral Proximity Switch
SW-8 See 6.1 4125831 Parking Brake Proximity Switch
SW-9 See 16.1 3001279 Hydraulic Oil Level Switch
SW-10 See 3.1 554390 Seat Switch 68080 - 1601 ~ 2156
SW-10 See 3.1 4139450 Seat Switch 68080 - 2157 and Up
SW-11 See 4.1 2721505 Mow Switch
SW-12 See 4.1 1004290 Joystick
SW-13 Not Shown 554018 Engine Oil Pressure Switch Included in Engine
To Next Page
