AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
1003288.7 1 Treadle Pivot
2 352726 2 • Bushing
3 3007230 1 Stop, Mow Speed
4 3003474 1 Grip, Pedal
5 3003475 1 Grip, Pedal
6 366974 2 Rod End
7 4125831 1 Switch, Proximity REFERENCE SW-7, See 42.1
8 3006327 1 Shaft, Turn Assist
9 333542 1 Tie Stud
10 3006998 1 Rod, Hydro
11 4176562 1 Bracket, Hydro Mount
12 4132912 1 Pedal, Hydro
13 471214 1 Fitting, Grease
14 446136 2 Lockwasher, 5/16 Heavy
15 452004 4 Flat Washer, 1/4
16 440042 4 Bolt, Carriage 1/4 - 20 UNC x 3/4
17 443102 4 Nut, 1/4 - 20 Hex Head
18 444718 1 Locknut, 5/16-18 Center
19 400272 1 Screw, 3/8-16 x 2-1/4” Hex Head
20 445795 6 Nut, 5/16-18 Spiralock Flange
21 400182 2 Screw, 5/16-18 x 5/8” Hex Head
22 443112 2 Nut, 3/8-24 Hex
23 452008 2 Flat Washer, 3/8
24 446128 4 Lockwasher, 1/4
25 3002695 1 Washer
26 400188 7 Screw, 5/16-18 x 1” Hex Head
27 445796 6 Nut, 3/8-16 Spiralock Flange
28 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
29 3008383 1 Clip, Wire Harness
30 4176580 1 Plate, Proximity Switch Mount
31 4182392 1 Bracket, Neutral Switch
32 800440 2 Screw, #4-40 x 1
33 308404 2 Flat Washer, .12 .25 .02 YS
34 446102 2 Washer, Lock #4 Reg.
35 444302 1 Nut, #4 - 40 Hex
