41
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
4142455 1 Bracket, Brake
2 4125831 1 Switch, Proximity REFERENCE SW-8, See 42.1
3 3006327 1 Shaft, Turn Assist
4 3007606 1 Lever, Parking Brake
5 3006997 1 Mount, Brake
6 1003616 1 Brake Arm
7 352726 2 • Bushing
8 471214 1 Grease Fitting
9 446136 2 Lockwasher, 5/16 Heavy
10 452004 4 Flat Washer, 1/4
11 800440 2 Screw, #4 - 40 x 1”
12 1003872 1 Pedal
13 444718 2 Locknut, 5/16-18 Center
14 445795 8 Nut, 5/16-18 Spiralock Flange
15 441602 8 Carriage Bolt, 5/16-18 x 3/4”
16 400182 2 Screw, 5/16-18 x 5/8” Hex Head
17 443102 4 Nut, 1/4-20 Hex
18 400188 2 Screw, 5/16-18 x 1” Hex Head
19 4108161 2 Brake Spring Assembly
20 3008383 1 Clip, Wire Harness
21 443812 2 Nut, 3/8-24 Hex Jam
22 461451 2 Clevis Pin, 5/16 x 15/16”
23 460014 2 Cotter Pin, 3/32 x 3/4”
24 4176580 1 Plate, Proximity Switch Mount
25 440042 4 Bolt, Carriage 1/4-20 x 3/4”
26 4182391 1 Bracket, Brake Switch
27 REF Brake Cable See 8.1
28 446128 4 Lockwasher 1/4 Regular
29 308404 2 Flat Washer, .12 .25 .02
30 446102 2 Lockwasher #4
31 444302 2 Nut, #4-40 Hex
To Next Page
