43
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
4118092 1 Frame
2 366871 2 • Bushing
3 4113047 6 Screw, 5/8-18 x 1-1/2” Hex Head Grade 8 Bolt
4 4140094 6 Flat Washer, 5/8
5 452016 6 Flat Washer, 5/8
6 443128 6 Nut, 5/8-18 Hex
7 445795 2 Nut, 5/16-18 Spiralock Flange
8 441602 1 Bolt, 5/16-18 x 3/4” Carriage
9 4120961 1 Battery Tray
10 2810553 1 Clamp, Battery
11 400188 1 Screw, 5/16-18 x 1” Hex Head
12 67844 1 ROPS Assembly
13 5000465 8 • Screw, 1/2-13 x 1-1/4” Hex GR 8
14 446154 8 • Lockwasher, 1/2 Heavy
15 400370 2 • Screw, 7/16-20 x 1” Hex Head Grade 8
16 446148 2 • Lockwasher
17 557844 1 • Decal, ROPS Structure Warning
18 5002952 1 • Decal, ROPS Seat Belt Warning
19 4139437 1 • Seat Belt Kit
20 REF 1 Front Axle See 8.1
To Next Page
