51
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
4149337 2 Tire, 22.5 x 10-8 4 Ply
2 1003638 2 Rim
3 360111 2 Inflation Valve
4 361648 6 Washer, Thrust
5 361647 2 Bearing, Thrust
6 471214 2 Fitting, Grease
7 461393 2 Pin, Spring 1/4 x 2”
8 4151058 1 Steering Axle
9 3010489 4 • Bushing
10 4137137 1 Cylinder, Steering
4137139 1 • Seal Kit
11 443840 2 Nut, 1-12 Hex Jam
12 452022 1 Flat Washer, 1
13 366789 1 Spacer, Axle
14 460064 1 Cotter Pin, 1/4 x 1-1/2”
15 460026 2 Cotter Pin, 1/8 x 3/4”
16 4141925 2 Ball Joint
400194 2 • Screw, 5/16-18 x 1-3/4”
444718 2 • Locknut, 5/16-18 Hex
17 445666 2 • Nut, 1/2-20 Slotted Hex
18 4132688 1 Tie Rod See 10.1
19 4149118 2 Motor Mount
20 400410 8 Screw, 1/2-13 x 1-3/4” Hex Head
21 361451 2 Washer, Thrust
22 471227 1 45° Grease Fitting
23 460028 2 Cotter Pin, 1/8 x 1”
24 460032 2 Cotter Pin, 1/8 x 1-1/2”
25 2000012 2 Hub, Wheel
26 353914 8 Wheel Bolt
27 367350 2 Washer, Thrust
28 4132699 1 Arm, Left Steering
29 4141934 1 Arm, Right Steering
30 446154 14 Lockwasher, 1/2 Heavy
31 400406 6 Screw, 1/2-13 x 1-1/4” Hex Head
32 4118255 2 Wheel Motor, Disk Valve See 36.1
33 554780 2 • Key
34 554779 2 • Nut
To Next Page
