55
> Change from previous revision
AR-522
Item Part No. Qty. Description Serial Numbers/Notes
1
4118253 1 Engine, V2003 MT
4113986 1 • Filter, Engine Oil See 11.1
2 310711 12 Washer, Isolator
3 362263 1 Screw, M10-1.25 x 25mm Hex Head
4 363485 1 Lockwasher, M10 Heavy
5 364501 1 Temperature Sender
6 365979 7 Screw, M12-1.25 x 25mm Hex Head
7 365981 4 Screw, M14-1.5 x 25mm Hex Head
8 367031 4 Washer, Isolator
9 400190 8 Screw, 5/16-18 x 1-1/4” Hex Head
10 400276 4 Screw, 3/8-16 x 3” Hex Head
11 4120309 1 Engine Mount, Right Side Front
12 4120311 1 Engine Mount, Left Side Front
13 4120313 1 Engine Mount, Left Side Rear
14 4120315 1 Engine Mount, Right Side Rear
15 4133840 4 Isolator, Engine
16 4174240 1 Cable, Throttle
17 4173042 1 Bracket, Oil Pan Protection
18 446142 4 Lockwasher, 3/8 Heavy
19 446154 7 Lockwasher, 1/2 Heavy
20 446160 4 Lockwasher, 9/16 Heavy
21 453013 1 Flatwasher, 7/16
22 453017 7 Flatwasher, 1/2
23 443110 4 Nut, 3/8-16 Hex
24 445795 8 Nut, 5/16-18 Spiralock Flange
25 400108 1 Screw, 1/4-20 x 3/4” Hex Head
26 4135765 1 Stud, M8-1.25
27 453023 2 Flat Washer, 1/4
28 444708 1 Locknut, 1/4-20 Center
To Next Page
