CONTROLS 4
en-37
4.2.6.34 INCLINOMETER_________________________________________________________
NOTE: A Jacobsen Dealer or service technician must activate the
Inclinometer function in the menu system after the Inclinometer Accessory or
Premium Seat is installed.
Navigate to the PIN Menu. See 4.2.6.16
Use the UP and DOWN arrow keys until the green arrow is
next to Inclinometer. Press the select button to select Inclinometer.
Use the UP and DOWN arrow keys until the green arrow is
next to Enable or Disabled. Press the select button to accept.
Press the back button to return to previous menu.
4.2.6.35 SET DEFAULT PARAMETERS
Navigate to the PIN Menu. See 4.2.6.16
Use the UP and DOWN arrow keys until the green arrow is
next to Set Default Parameters. Press the select button to select Set
Default Parameters.
Press the select button for five seconds to reset the mower to default
parameters.
NOTE: Some parameters below may not apply, depending on options
installed on the mower.
Default Parameters
Speed Units - MPH Transport Speed - 12 MPH
Temperature Units - °F Mow Speed - 7 MPH
Date Format - MM/DD/YYYY Turn Speed - 7 MPH
One Touch - Enabled Reverse Speed - 5 MPH
Brightness - 100% Manual Throttle - 75%
Reversing Fan Mode - Automatic Garage Throttle - 30%
Reversing Fan Duration - 10 Seconds Transport/Mow Throttle - 100%
Reversing Fan Interval - 30 Minutes Start Throttle - 50%
Weight Transfer - Enabled Idle Throttle - 0%
Inclinometer - Enabled
AWD in Mow - Enabled
Press the back button to return to previous menu.
Disabled
Enabled
Tilt Sensing Technology
One Touch
Vehicle Speed
Change PIN
Inclinometer
Set Default Parameters
Fan Drive
PIN Menu
One Touch
Vehicle Speed
Change PIN
Inclinometer
Set Default Parameters
Fan Drive
PIN Menu
Hold confirmation button for 5 seconds
to reset to default settings
Reset To Defaults
To Next Page
