4 CONTROLS
en-40
4.2.6.39 RESET SERVICE HOURS _________________________________________________
Navigate to the PIN Menu. See 4.2.6.16
Use the UP and DOWN arrow keys until the green arrow is
next to Set Default Parameters. Press the select button to select Reset
Service Hours.
NOTE: Only reset the service hours after the required service has been
performed on the mower. Failure to complete required service can void the
mower’s warranty.
Press the select button for five seconds to reset the service hours.
Press the back button to return to previous menu.
WARNINGS
4.2.6.40 WARNING SLOPE ANGLE - ANGLE ALERT __________________________________
During work if the machine is driven on a slope greater than 16° the screen
will display this warning. This over rides all other information, and will continue
until the machine has been driven to an area with a slope of less than 13°.
The engine will stop if a slope angle of 42° is achieved.
NOTICE
The number in the top right of the screen indicates the total number of current faults recorded. If more than one fault,
it will cycle all current faults.
Change PIN
Inclinometer
Set Default Parameters
Fan Drive
Weight Transfer Pressure
Reset Service Hours
PIN Menu
Hold confirmation button for 5 seconds
to reset current Service Hours
Main Menu
12:00:00 1/1/2016
0.0 Hours
TST
™
!
Incline is 16°.
Approaching Unsafe Angle.
1/1
