55
> Change from previous revision
ECLIPSE
Item Part No. Qty. Description Serial Numbers/Notes
1
63305 1 Gen-Set Power Module See 19.1
2 63306 1 Battery Power Module See 20.1
3 4166900 1 Controller, Eclipse
4 400110 4 Screw, 1/4-20 x 1” Hex Head
5 453023 4 Flat Washer, 1/4
6 444708 4 Locknut, 1/4-20 Center
7 4165263 1 Mount, Fixed Head Power Module
Used on 63300, 63302, 63304,
63311, 63313, 63315
7 4164220 1 Mount, Floating Head Power Module
Used on 63301, 63303, 63312,
63314
8 400228 4 Screw, 5/16-24 x 1-1/4” Hex Head
Used on 63300, 63302, 63304,
63311, 63313, 63315
8 400226 2 Screw, 5/16-24 x 1” Hex Head
Used on 63301, 63303, 63312,
63314
9 400244 2 Screw, 5/16-24 x 2-3/4” Hex Head
Used on 63301, 63303, 63312,
63314 Only
10 446136 4 Lockwasher, 5/16
11 4167640 2 Cable Tie, Tree
12 4172240 1 Decal, Front Roller Weight
13 447212 1 Lockwasher, 1/4 Internal Tooth
To Next Page
