59
> Change from previous revision
ECLIPSE
Item Part No. Qty. Description Serial Numbers/Notes
1
4140145 1 Frame, R.H. Side
2 4163680 1 Frame, L.H. Side
3 4168481 1 18” Front Crossbar Used on 63301and 63314
3 4140147 1 22” Front Crossbar Used on 63303 and 63312
4 4168480 1 18” Rear Crossbar Used on 63301and 63314
4 4140148 1 22” Rear Crossbar Used on 63303 and 63312
5 400258 6 Screw, 3/8-16 x 3/4” Hex Head
6 446142 10 Lockwasher, 3/8 Heavy
7 366796 2 Kickstand, Mounting Bracket
8 400262 2 Screw, 3/8-16 x 1” Hex Head
9 400260 3 Screw, 3/8-16 x 7/8” Hex Head
10 400268 2 Screw, 3/8-16 x 1-3/4” Hex Head
11 443810 4 Nut, 3/8-16 Hex Jam
12 4127931 1 Decal, Patent
13 REF 1 Serial Plate
14 4117466 1 Decal, 96 db Noise
15 1000018 1 18” Kickstand Used on 63301and 63314
15 132674 1 22” Kickstand Used on 63303 and 63312
16 444850 3 Nut, 3/8-16 Center Lock Jam
17 364164 1 Spring
18 4140144 1 Limit Bracket
19 400230 2 Screw, 5/16-24 x 1-1/2” Hex Head
20 332844 2 Spring, Compression
21 453009 6 Flat Washer, 5/16
22 4169840 1 Decal, Danger
23 443808 2 Nut, 5/16-24 Hex Jam
24 4174680 1 Decal, Weight
To Next Page
