Jacobsen Eclipse 118 63313 - Page 125

77
> Change from previous revision
ECLIPSE
Item Part No. Qty. Description Serial Numbers/Notes
1
446116 2 Lockwasher, #10
2 2000148 1 Bracket, Bearing
3 2811071 1 Belt, Polychain, 80 Tooth
4 2811223 1 Pully, 18 Tooth
5 2811107 1 Pully, 112 Tooth
6 3001273 1 Shaft
7 2811110 1 Fixed Head Pulley Cover
Used on 63300, 63302, 63305,
63311, 63313 and 63315
7 4140154 1 Floating Head Pulley Cover
Used on 63301, 63303, 63312 and
63314
8 4102241 1 Cover, Belt
9 4104641 1 Belt, 130 Tooth
10 2811108 1 Pulley, 23 Tooth
11 4152677 1 Mount, Motor
12 4160533 1 Motor, Brushless Bi-Directional Reference M1, See 22.1
13 463029 1 Key, Woodruff
14 367554 2 Bearing, Needle
15 446130 3 Lockwasher, 1/4 Heavy
16 444708 3 Locknut, 1/4-20 Center
17 400190 2 Screw, 5/16-18 x 1-1/4” Hex Head
18 452006 1 Flat Washer, 5/16
19 446134 1 Lockwasher, 5/16
20 443106 1 Nut, 5/16-18 Hex
21 434023 1 Screw, 14-20 x 1-1/4” Socket Head
22 400262 2 Screw, 3/8-16 x 1” Hex Head
23 453011 2 Flat Washer, 3/8
24 446142 2 Lockwasher, 3/8 Heavy
25 443110 2 Nut, 3/8-16 Hex
26 434034 2 Screw, 10-24 x 1” Socket Head
27 400106 3 Screw, 1/4-20 x 5/8” Hex Head
28 434031 1 Screw, 1/4-20 x 3/4” Socket Head
29 403744 3 Screw, #10-24 x 1/2” Hex Head
30 359864 AR Thrust Washer
31 366707 1 Ball Bearing
32 443806 2 Nut, 5/16-24 Hex Jam
33 452002 3 Flat Washer, #10
Used on 63301, 63303, 63312 and
63314
34 434042 2 Screw, 1/4-20 x 1-1/2” Socket Head
