Jacobsen Eclipse 118 63313 - Page 137

89
ECLIPSE
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B1 See 21.1 N/S 12 Volt SLA Battery
Obtain batteries localy or
through your Jacobsen Dealer
Battery Power Module Only
B2 See 21.1 N/S 12 Volt SLA Battery
B3 See 21.1 N/S 12 Volt SLA Battery
B4 See 21.1 N/S 12 Volt SLA Battery
CB1 See 3.1 4169341 25 Amp Circuit Breaker Included with Harness
F1 See 21.1 4105800 50 Amp Fuse (Main) Battery Power Module Only
M1 See 15.1 4160533 Traction Motor
M2
See 7.1 or
10.1
4160533 Reel Motor Fixed Head Units
R1 See 1.1 4136324 Hand Throttle Potentiometer
R2 See 1.1 4145428 Bail Lever Potentiometer
SW1 See 3.1 4165020 Key Switch
SW2 See 3.1 4165062 Reel Switch
U1 See 11.1 4139448 M806A Controller
U2 See 3.1 4136331 LCD Display
U3 See 19.1 4166120 Generator, 1kW Gen-Set Power Module Only
U4 See 21.1 4171680 Battery Gauge Battery Power Module Only
