5 CONTROLS
5.1 OPERATOR WORKSTATION __________________________________________
5.2 - Control Panel
5.3 - Throttle Control
5.4 - Armrest Adjuster
5.5 - Traction Pedal
5.6 - Mow Speed Lever
5.7 - Steering Tilt Lever
5.9 - Tow Valve
5.10 - Brake Valve (Under Floorboard)
5.6
5.5
5.4
5.2
5.3
5.7
5.10
5.9
