FUSES AND RELAYS 11
FUSES
RELAYS
Component Rating Type Description
F1 10 Amp Mini
Accessory Socket, 4WD Relay (R5).
F2 40 Amp Mini
Glow Plug Relay (R2), Glow Plugs.
F3 30 Amp Mini
Run Relay (R1).
F4 15 Amp Mini
Console Interlock, Work Light.
F5 30 Amp Mini
Fan Power.
F6 20 Amp Mini
Marlin Controller Power Feed (Pin 6 &7), Ignition Run.
F7 20 Amp Mini
Marlin Controller Power Feed (Pin 1 &4), Run Relay.
F8 10 Amp Mini
Cross Cut Switch, Console Interlock, Forward
Proximity Switch, Seat Switch, Seat Switch (Air Ride
Seat, Fan Relay (R4).
F9 30 Amp Mini
Starter Relay (R3), Starter Motor.
F10 5 Amp Mini
Run Relay (R1), Marlin Controller.
Component Rating Type Description
R1
SPDT N/C=20 Amp
+ N/O 35 Amp
Micro 280 Run Relay (Part Number 4333409), also known as K1.
R2
Standard Glow Plug Relay (Part Number 4193880), also known as
K2.
R3
SPDT N/C=20 Amp
+ N/O 35 Amp
Micro 280 Starter Relay (Part Number 4333409), also known as K3.
R4
SPDT N/C=20 Amp
+ N/O 35 Amp
Micro 280 Fan Relay/ Fan Control (Part Number 4333409), also
known as K4.
R5
SPDT N/C=20 Amp
+ N/O 35 Amp
Micro 280 4WD Relay (Part Number 4333409), also known as K5.
