19
> Change from previous revision
FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
153215 2 Handle, Clutch
2 241815 2 Fork, Clutch
3 3003158 1 Spring, Left Side Clutch Handle
4 3003157 1 Spring, Right Side Clutch Handle
5 315861 2 Washer
6 460026 2 Cotter Pin, 1/8 x 3/4”
7 203975 2 Wheel, Pawl
8 315867 8 Pin, Pawl
9 241810 8 Pawl
10 460012 8 Cotter Pin, 3/32 x 5/8”
11 500236 2 Wheel Cylinder
12 500534 2 • Bearing, Cup and Cone
13 453022 2 Flat Washer, 3/4
14 445686 2 Nut, 3/4-16 Hex Castle
15 460028 2 Cotter Pin, 1/8 x 1”
16 220275 2 Gear, Main Drive
17 315928 2 Gasket, Housing Cover
18 203986 2 Cover, Housing
19 407706 18 Screw, 1/4-20 x 7/8” Oval Head Includes External Tooth Lockwasher
20 315876 2 Gasket, Reel Bearing Cover
21 352635 2 Cover, Reel Bearing
22 408052 10 Screw, #12-24 x 1/2” Hex Head Includes Internal Tooth Lockwasher
23 315967 2 Seal, Drive Hub
24 203984 2 Hub, Ground Wheel
25 204119 2 Cap, Hub
26 327676 2 Tab, Locking
27 400106 2 Screw, 1/4-20 x 5/8” Hex Head
To Next Page
