SPECIFICATIONS 3
5
3 SPECIFICATIONS
3.1 PRODUCT IDENTIFICATION _________________________________________________
71105 ..............................30 Inch, 6 Blade Fairway mower.
71351..............................30 Inch, 10 Blade Fairway Mower
Serial Number ................An identification plate, like the one
shown, listing the serial number, is
attached to the right side gear
housing.
Always provide the serial number of the unit when ordering
replacement parts or requesting service information.
3.2 MOWER__________________________________________________________________
Cutting Width ..................30 in. (762 mm) each unit.
Gears ..............................Precision machine cut
Reel Diameter.................8 in. (203 mm)
Number of Blades ...........6 or 10
Drive................................Separate train of gears for each
ground wheel
Clutch..............................Separate clutch for each ground
wheel
Bearings..........................Tapered roller bearing for reel and
ground wheels. Roller bearing for
intermediate gear.
Lubrication ...................... All gears and bearings lubricated
from main reservoirs. Use Texaco
Multiflak HD00 or equivalent.
Bedknife.......................... Made from oil hardened special
alloy steel.
Height of Cut:
17 in. Steel Wheel.... 3/8 to 2-7/8 in. (10 to 73 mm)
18 in. Steel Wheel.... 3/8 to 2-15/16 in. (10 to 74 mm)
4 x 17 Wheel............ 7/16 to 2-3/4 in. (11 to 70 mm)
4 x 20 Wheel............ 11/16 to 3-7/16 in. (17 to 87 mm)
3.3 ACCESSORIES AND SUPPORT LITERATURE __________________________________
Contact your area Textron Turf Care And Specialty
Products Dealer for a complete listing of accessories and
attachments
18 in. (457 mm) Steel Wheel ...................................... 70087
17 in. (432 mm) Steel Wheel ...................................... 70089
4 x 20” Semi-Pneumatic Wheel .................................. 70086
4 x 17” Semi Pneumatic Wheel................................... 70088
Micro Height Adjuster.................................................. 71001
Rear Roller Scraper (Set of 7) .................................... 69065
Orange Paint (12 oz. Spray) ..................................... 554598
8 oz. Tube OO Grease............................................ 5000068
Grinding Instructions Manual .................................... 549595
Service Manual ......................................................... 545709
Lapping Compound:
80 Grit, 10 lb (4.5 kg) Pail............................... 5002488
80 Grit, 25 lb (11.3 kg) Pail............................. 5002490
120 Grit, 10 lb (4.5 kg) Pail............................. 5002489
120 Grit, 25 lb (11.3 kg) Pail........................... 5002491
RACINE, WI
MADE IN U.S.A.
TEXTRON TURF CARE AND SPECIALTY PRODUCTS
71105 1601
