Jacobsen Greens King 522 E - English; Default Chapter; Table of Contents

GB-1
CONTENTS
1 CONTENTS
1 CONTENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 OPERATING SAFETY . . . . . . . . . . . . . . . . . . 2
2.2 IMPORTANT SAFETY NOTES . . . . . . . . . . . . 3
3 CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 ICONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 SET UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.2 INITIAL INSPECTION . . . . . . . . . . . . . . . . . . . 5
4.3 BATTERY INSTALLATION . . . . . . . . . . . . . . . 6
4.4 ASSEMBLE BATTERY PACKTO MOWER . . . 7
4.5 OPERATING CHECKS . . . . . . . . . . . . . . . . . . 7
4.6 OPERATOR PRESENCE CONTROL . . . . . . . 7
5 ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . 8
5.1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.2 REEL TO BEDKNIFE . . . . . . . . . . . . . . . . . . . 8
5.3 BEDKNIFE ADJUSTER . . . . . . . . . . . . . . . . . 8
5.4 BEDKNIFE . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.5 BRAKE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.6 CUTTING HEIGHT . . . . . . . . . . . . . . . . . . . . 10
5.7 BELT ADJUSTMENT . . . . . . . . . . . . . . . . . . 10
5.8 HANDLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
5.9 OPC SWITCH ADJUSTMENT . . . . . . . . . . . .11
5.10 THROTTLE SPRING ADJUSTMENT . . . . . . .11
5.11 THROTTLE CABLE ADJUSTMENT . . . . . . . 12
5.12 FRONT ROLLER WEIGHT . . . . . . . . . . . . . . 12
5.13 TORQUE SPECIFICATION . . . . . . . . . . . . . . 13
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
© COPYRIGHT 2001, TEXTRON INC.
“All rights reserved, including the right to reproduce this book or portions thereof in any form”.
A
ll information in this publication is based on information available at time of approval for printing. Textron Golf, Turf &
S
pecialty Products reserves the right to make changes at any time without notice and without incurring any obligation
.
LITHO IN U.S.A. 10-2002
