CNC:
Index Service Part #File Name
Description
Qty
1 A00-0095 TEKT-0057 ROPS Isolator 2
2 A00-0353 TEKT-0143 New Condensor Assembly, Kalori 1
3 A00-0359 FLANGE-NUT-10-32 Flange Nut, 10-32 6
4 A00-0360 SCREW-10-32X1-2 Screw, 10-32 x 1/2" 6
5 Ja5-0006 JA9016-ASM-13 Rear Bracket Weldment 1
6 Ja5-0020 JA9016-116 Rear Bracket Seal, Bottom 1
7 Ja5-0020 JA9016-117 Rear Bracket Seal Vertical 1
8 Ja5-0020 JA9016-127 RH Ndax Rear Bracket 1
Condenser/Rear Bracket Assembly
Daryl Furkalo
2015-08-12 Imp.
JA9016-ASM-30_OP
B
SCALE 0.200
