Jacobsen JMP653F User Manual

en-131
SPECIFICATIONS 12
12.9 CUTTER DECK SPECIFICATION ________________________________________
Product HR600 HR700
Deck Width 152 cm (60 inch) Deck (Front)
Construction Bull nose profile, steel construction. Solid bumper rails, bolted assembly of all impact and wearing parts.
Blade Length 533.4 mm (21 inch) 533.4 mm (21 inch)
Number of Blades 3 3
Blade Tip Speed 4207 m/minute (13 802 feet/minute)
Height of Cut
25 mm - 120 mm (1 inch - 4.75 inch) 6.5 mm (0.25
in) increments. Tools-less adjustment.
25 mm - 127 mm (1 inch - 5 inch) 12.7 mm (1/2 in)
increments. Tools-less adjustment.
Height of Cut Adjustment
Front
Two castor wheels, with spacers. tyres 9 x 3.50 -
4.00 smooth, semi pneumatic puncture proof,
sealed precision ball bearings.
Two castor wheels, with spacers. tires 11 X 4.00 - 5
smooth, pneumatic, taper roller bearings.
Height of Cut Adjustment
Rear
Front deck pin and slot.
“Anti Scalp” Roll Three anti scalp rollers on the front of deck and four anti scalp rollers on the rear.
Transmission By Hydraulic motor to each cutter blade.
Product HR600 HR700
Deck Width
89 cm (35 inch) Deck
(Wing)
101.6 cm (40 inch) Deck
(Wing)
111.8 cm (44 inch)
Deck (Wing)
152 cm (60 inch) Deck
(Wing)
Construction Bull nose profile, steel construction. Solid bumper rails, bolted assembly of all impact and wearing parts.
Blade Length 457.2 mm (18 inch) 533.4 mm (21 inch) 585.5 mm (23 inch) 533.4 mm (21 inch)
Number of Blades 2 2 2 3
Blade Tip Speed
4940 m/minute
(16 207 feet/minute)
4207 m/minute
(13 802 feet/minute)
4608 m/minute
15 118 feet/minute)
4207 m/minute (13 802
feet/minute)
Overall Width Of Cut 299.5 cm (118 inch) 328.4 cm (129.3 inch) 347.9 cm (137 inch) 427 cm (168 inch)
Height of Cut
25 mm - 120 mm (1 inch - 4.75 inch) 6.5 mm (0.25 in) increments. Tools-less
adjustment.
25 mm - 127 mm (1
inch - 5 inch) 12.7 mm
(1/2 in) increments.
Tools-less adjustment.
Height of Cut Adjustment
Front
Two castor wheels, with spacers. tyres 9 x 3.50 - 4.00 smooth, semi pneumatic
puncture proof, sealed precision ball bearings.
Two castor wheels, .
tires 11 X 4.00 - 5
smooth, pneumatic,
taper roller bearings.
Height of Cut Adjustment
Rear
Chain and Pin
One castor wheel, with
spacers. tires 11 X
4.00 - 5 smooth,
pneumatic, taper roller
bearings. Wing deck
chain and Pin
“Anti Scalp” Roll Three anti scalp rollers on the front of deck and four anti scalp rollers on the rear.
Two anti scalp rollers
5 X 2.75 on the front
of deck and one anti
scalp roller 3in on the
rear.
Transmission By Hydraulic motor to each cutter blade.

Jacobsen JMP653F Specifications

General

Brand	Jacobsen
Model	JMP653F
Category	Lawn and Garden Equipment
Language	English
