en-21
CONTROLS 5
5.2.E CUTTER SWITCH (PTO)________________________________________________
Switches the Cutters On and Off when machine is in Mow mode
(See Section 6.10).
Push top of the PTO rocker switch to start the cutters.
Push bottom of the PTO rocker switch to stop the cutters.
5.2.F 4WD IN REVERSE SWITCH _____________________________________________
Engages 4 wheel drive whilst the vehicle is reversing. The switch
must be held to engage.
5.2.G LIGHT SWITCH (OPTIONAL)____________________________________________
Switches the road lights on and off.
Position 1. OFF*
Position 2. Side / Marker Lights
Position 3. Main Beam.
NOTE: Position 3 requires ignition to be on.
*Also there are daylight running lamps installed that automatically come on
when the ignition is switched on.
5.2.H ROTATING BEACON (OPTIONAL) ______________________________________
Operates the vehicles rotating beacon when a cab is not fitted.
