Page #105 background image
73
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
445795 AR Nut, 5/16-18 Spiralock Flange
2 441614 1 Carriage Bolt, 5/16-18 x1”
3 3007558 AR Clamp, Double Tube
4 345666 AR Clamp, 1/2” I.D.
5 409811 AR Screw, 5/16-18 x 5/8” Thread Cutting
6 445794 AR Locknut, 1/4-20 Spiralock Flange
7 3003473 AR Clamp, Double Tube
> 8 367090 2 Clamp, 1” I.D. 7-Gang
9 400122 AR Screw, 1/4-20 x 2-1/4” Hex Head
10 365566 AR Clamp, 1-1/4” I.D.
11 400118 2 Screw, 1/4-20 x 1-3/4”” Hex Head 7-Gang Units Only
12 367186 1 Clamp, Double Tube 4WD Only
13 400258 1 Screw, 3/8-16 x 3/4” Hex Head 7 Gang Units Only
14 445796 1 Nut, 3/8-16 Spiralock Flange 7 Gang Units Only
15 3003110 7 Clamp, Double Tube 7 Gang Units Only
16 2812240 5 Plate, Cover 7 Gang Units Only
17 400116 3 Screw, 1/4-20 x 1-1/2” Hex Head 7 Gang Units Only
18 444708 AR Locknut, 1/4-20 Center
19 3009645 1 Bracket, Hose Clamp 7 Gang Units Only
20 400188 1 Screw, 5/16-18 x 1” Hex Head 7 Gang Units Only
21 3009564 1 Bracket, Tube Clamp 7 Gang Units Only
22 360970 AR Clamp
23 364190 1 Clamp 7 Gang Units Only
24 400120 2 Screw, 1/4-20 x 2” Hex Head 7 Gang Units Only
