57
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
3001965 1 Air Filter
5000919 1 • Air Cleaner Element
5000920 1 • Cover
5000921 1 • Valve
2 3001388 1 Bracket, Air Filter
3 3006094 1 Shroud, Rear Frame
4 3006583 1 Bracket, Air Cleaner Mounting
5 3006585 1 Shroud, Radiator Fan
6 3005607 1 Oil Cooler
7 557367 1 Recovery Tank
8 557374 1 Tank, Stay
9 5003077 1 Radiator Includes Decal
550863 1 • Radiator Cap
10 3005604 2 Receptacle, #85 1/4 Turn
11 3005608 1 Mount, Radiator
12 3006026 2 Bracket, Radiator
13 3006584 1 Hose, Air Cleaner Intake
14 2810158 1 Hose, Radiator Outlet
15 4169423 1 Hose, Pipe to Turbo Intake
16 4183402 1 Hose, Radiator Inlet
17 3005609 1 Mount, Oil Cooler
18 358971 2 Mounting Block, Rubber
19 365398 1 Indicator, Air Cleaner
20 444718 1 Locknut, 5/16-18 Center
21 345666 2 Clamp
22 400188 6 Screw, 5/16-18 x 1” Hex Head
23 445796 6 Nut, 3/8-16 Spiralock Flange
24 400182 15 Screw, 5/16-18 x 5/8” Hex Head
25 400200 2 Screw, 5/16-18 x 2-1/2” Hex Head
26 445640 2 Nut, 3/8-16 Steel Wing
27 3002195 1 Elbow, 90°
28 445795 2 Nut, 5/16-18 Spiralock Flange
29 3005603 2 Retainer
30 3005605 2 Stud, #85 1/4 Turn
31 359615 2 Clamp, Hose
32 326112 4 Clamp, Hose
33 452006 21 Flat Washer, 5/16
34 446136 13 Lockwasher, 5/16 Heavy
35 3008132 2 Seal, Tube
36 367458 2 Clamp, Hose
37 3008474 2 Clamp, Tube
38 366526 1 Clamp, Hose
39 452008 2 Flat Washer, 3/8
40 3008383 1 Clip, Harness
41 5003447 1 Hose, Radiator Overflow, Bulk
42 10894-02 2 Clamp, Hose
43 4169424 1 Hose, Air Cleaner to Pipe
44 4168440 1 Pipe, Hose Connection
45
7332 AR Hose, 7/16” Fuel
