SET UP 3
11
3 SET UP
3.1 INITIAL INSPECTION _______________________________________________________
The set-up and testing of the unit should always be
performed by a trained technician familiar with the
operation of this equipment.
Read each instruction completely and make sure you
understand it before proceeding with the assembly. Stay
alert for potential hazards and obey all safety
precautions.
The RIGHT and LEFT, FRONT and REAR of the
machine are referenced from the operator’s seat, facing
forward.
Accessories not included with this product must be
ordered separately. See instructions provided with
accessory for installation and parts.
3.1 INITIAL ASSEMBLY ________________________________________________________
1. Check tires for proper inflation. Tires have been over
inflated for transport.
Mower:
Front - 16-20 psi (110-138 kPa)
Rear - 10-12 psi (69-83 kPa)
Deck - 20-25 psi (138-173 kPa)
2. Check battery connections
Make absolutely certain the ignition switch is “Off”
and the key has been removed before servicing the
battery.
Verify battery polarity before connecting or
disconnecting the battery cables.
When installing the battery, always assemble the
RED, positive (+) battery cable first, and the ground,
BLACK, negative (-) cable last.
Make sure battery is properly installed and secured
to the battery tray.
Tighten cables securely to battery terminals and
apply a light coat of silicone dielectric grease to
terminals and cable ends to prevent corrosion. Keep
vent caps and terminal covers in place.
3. Cut bands securing front deck and lower front deck
to the ground.
4. Check that front deck is leveled. [Section 4.15]
5. Set cutting height to customer specification.
[Section 4.14]
6. Check engine oil and add fuel to tank. Start engine.
7. Raise wing lift arms to thier fully raised position.
8. Remove shipping bands, disengage wing transport
latches, and lower wing mowers to the ground. If
mowers will not lower, adjust weight transfer knob
as required. [Section 4.8]
CAUTION
Do not attempt to drive the mower unless you are
familiar with this type of equipment and know how to
operate all controls correctly.
WARNING
Make sure the mower is parked on a solid and level
surface. Never work on a mower that is supported
only by the jack. Always use jack stands.
CAUTION
Always use insulated tools, wear protective glasses or
goggles and protective clothing when working with
batteries. You must read and obey all battery
manufacturer’s instructions.
WARNING
Never operate the engine without proper ventilation;
exhaust fumes can be fatal when inhaled.
NOTICE
Allow engine to operate at low idle for at least one
minute before operating mower.
When starting engine at temperatures below 40° F (4°
C), operate the engine at low idle for five minutes to
prevent damage to engine or hydraulic system.
