Jacobsen R-311 Dealer's Manual

CONTROLS 2
5
2 CONTROLS
2.1 ICONS ___________________________________________________________________
WARNING
Never attempt to drive the mower unless you have read the Safety and Operation Manual
and know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the
location and purpose of all the controls and gauges before operating this mower.
Coolant
Temperature
D
Read Manual
Engine Throttle
High Low
Hour Meter
Parking Brake Diesel Fuel
Implement Position
Left Center Right
Cruise Control
Engine
Off Run Start
Service Brake
Drive Mode
2WD 4WD 4WD
Momentary
Engine Oil
Air Filter
Traction
Forward Reverse
PTO Switch
Engage Disengage
Filter ServiceLights
Work Road
Horn
Cutting Units
Raise Lower
Hydraulic Oil
Temperature Pressure
Glow Plug
Weight Transfer
to Decks
Increase Decrease
Engage
Disengage
Filter Service
!
