57
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
346006 1 Cable, Grounding
2 400190 2 Screw, 5/16-18 x 1-1/4” Hex Head
3 400272 4 Screw, 3/8-16 x 2-1/4” Hex Head
4 3004523 4 Mount, Isolation
5 3004526 4 Washer, Mount Isolator
6 4121872.7 1 Bracket, Heat Shield
7 4121856.7 1 Muffler Shield
8 446142 4 Lockwasher, 3/8 Hvy
9 452004 4 Flat Washer, 1/4
10 443110 4 Nut, 3/8-16 Hex
11 444718 2 Locknut, 5/16-18 Center
12 361005 3 Bolt, M8-1.25 x 25mm
13 446136 13 Lockwasher, 5/16 Hvy
14 400108 2 Screw, 1/4-20 x 3/4” Hex Head
15 446130 6 Lockwasher, 1/4 Heavy
16 443102 2 Nut, 1/4-20 Hex
17 400106 4 Screw, 5/16-18 x 5/8” Hex Head
18 443106 1 Nut, 5/16 Hex
19 452006 5 Flat Washer, 5/16
20 457016 6 Washer, 5/16 x 1/16”
21 400186 8 Screw, 5/16-18 x 3/4” Hex Head
● 67043-1601~3969 units updated with 4123033 Muffler Kit and 4124824 Stay Bar Kit
