Jacobsen TURFCAT-623D User Manual

43
600 Series
Turfcat
Tractors
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
13-1 4118636 CYLINDER-LIFT 1
13-2 198042 VALVE-HYDRAULIC 1
13-3 148132 HYDROST STEER GEAR 1
13-4 2198259 TANK-HYDRAULIC 700 1
13-5 2198196 TRANSMISSION-EATON 1
13-6 118017 FILTER ELEMENT 10 MIC. 1
13-7 148354 HEAD-FILTER 1
13-8 2721535 OIL COOLER 1
13-9 4118238 CYLINDER-STEERING 1
(USE SEAL KIT 4118238-01)
13-10 2198108 VALVE-RELIEF 1
13-11 158006-01 FITTING-ORS/ORB 5
13-12 2690026-01FTG-RUN TEE 3/8 ORB 1
13-13 69206-05 HOSE-3/8 ORS/ORS 32.5 1
13-14 69206-14 HOSE-3/8 ORS/ORS 37.5 1
13-15 2692234-02HOSE-3/8 ORS-1/2 ORS 1
13-16 2692247-01HOSE-3/8 37/45 ORSX39.0 1
13-17 2690017-03FTG-ORB PLUG-06 1
13-18 158056-01 FITTING-ORS/O-RING TEE 1
13-19 158056-02 FTG-ORS/O-RING TEE 1
13-20 2198261 TUBE-VALVE TO COOLER 1
13-21 2692230-05HOSE-3/8 37/ORS X 32.75 1
13-22 2692230-04HOSE-3/8 37/ORS X 33.75 1
13-23 2692297-01HOSE-CHARGE TO RELIEF 1
13-24 2692269-01HOSE-3/8 37/ORS X 87.00 1
13-25 2692269-02HOSE-3/8 37/ORS X 82.50 1
13-26 65362-01 RUBBER-CLAMP 4IN 1
13-27 158006-06 FITTING-ORS/ORB 2
13-28 2198218 TUBE-STEERING CYL 1
13-29 2198264 HSE-MOLDED CASE OUT 1
13-30 158007-01 FITTING-90 ORS/ORB 2
13-31 2690011 FTG-10-3/4AD ORB/BRB-90 1
13-32 2198265 HOSE-MOLDED CHRG IN 1
13-33 158007-04 FITTING-90 ORS/ORB 1
13-34 2692272-01HSE-1/2 ORS/45ORSX18.0 1
13-35 158007-10 FTG-90 DEG ORS/ORB 1
13-36 2198260 TUBE-COOLER TO FILTER 1
13-37 69068-06 ORIFICE DISK 06, .070 1
13-38 158061-01 O-RING -06 1
13-39 158006-11 FITTING-ORB/ORS 2
13-40 108094-02 HOSECLAMP .50 TO 1.25 4
13-41 2690016-01FTG-10 ORB/3/4 HSE BRB 1
13-42 2690017-02FTG-ORB PLUG 20 1
13-43 148027 BREATHER VENT 1
13-44 148090 SUPPORT-TUBE 1/2 2
13-45 64123-80 BLT-HEX 1/4-20X1-1/4 1
13-46 64141-2 NUT-WLF 1/4-20 1
13-47 108138-02 TUBE CLAMP,.94 1
13-48 108094-01 CLAMP-HOSE SAE20 1
4114895-13
HYDRAULIC DIAGRAM
FIGURE 13
GNIR'O'TROPEAS
TRAP
REBMUN
EZISDAERHT #865-SA
01-160851 81-61/9 609-
11-160851 61-4/3 809-
21-160851 41-8/7 019-
31-160851 21-61/1-1 219-
41-160851 21-61/5-1 619-
61-160851 21-8/5-1 029-
30-160851 21-8/7-1 429-
SGNIR'O'ECAFTALF
TRAP
REBMUN
.D.OEBUT #865-SA
10-160851 "8/3 210
20-160851 "2/1 410
80-160851 "8/5 610
90-160851 "4/3 810
51-160851 "4/1-1 520
